Free Roof Pitch Chart Printables (PDF)
Diagrams
by julieleclerc
Figuring a roof's slope before you order materials saves money and second trips, and a roof pitch chart turns those rise-over-run numbers into a quick reference. This collection of 33 charts helps roofers, builders, and DIY homeowners convert pitch to angle and estimate shingle coverage without redoing the math each time.
Every chart comes as a print-ready PDF, so there's nothing to install. Print one for the truck, tuck a copy in the job folder, or tape it inside the garage for weekend projects. Download the chart that matches your work and keep it handy whenever a new slope question comes up.
When to use this Roof Pitch Chart template
- A roofer estimating shingle quantities for a 6/12 pitch roof needs to quickly cross-reference slope, angle, and coverage without calculating rise-over-run every time. These charts let them pull exact measurements in seconds, reducing material waste on job sites.
- A homeowner planning a DIY attic conversion wants to verify their contractor’s pitch calculations before purchasing trusses or rafters, so they can avoid costly framing mistakes or rework.
- A builder reviewing blueprints for a custom home must ensure the roof’s pitch aligns with local building codes and drainage requirements, using these charts to confirm angles match structural plans before ordering materials.
- A carpentry apprentice studying roof framing needs a visual reference to practice converting pitch fractions (like 4/12 or 9/12) into degrees, helping them build muscle memory for real-world jobs.
Which format should I download?
All templates in this collection are available exclusively as PDFs, which makes them ideal for print-and-use scenarios. Choose PDF because it’s universally compatible—no software installation is needed, and you can print directly from any device. The fixed layout ensures measurements stay precise, whether you’re taping a chart to a workbench or referencing it under a roof. For digital use, PDFs also allow easy sharing with teams or clients without worrying about formatting issues.
Choose from 33 Roof Pitch Chart Templates
How to use this Roof Pitch Chart template
Can I use these charts to calculate shingle square footage for a complex roof with multiple pitches?
These charts provide accurate conversions for single-pitch roofs, but complex roofs (like hips or valleys) may require additional calculations. Use the charts to determine the angle and slope of each section, then apply manufacturer-specific shingle coverage rates per square foot. For multi-pitched roofs, consult a takeoff software or a framer to ensure precise material estimates.
Do these charts account for local building code requirements for minimum or maximum roof pitches?
The charts focus on mathematical conversions between pitch, angle, and rise-over-run, not code compliance. Always verify your roof’s pitch against local building codes or consult a structural engineer, especially for projects in high-wind or heavy-snow regions. These templates serve as a tool to visualize measurements, not a substitute for professional review.
How do I adjust the chart if I need to mark it up with custom measurements during a project?
PDFs in this collection are print-ready but not editable. For custom annotations, print the chart on plain paper and use a fine-tip marker to add notes. Alternatively, screenshot the PDF and open it in an image editor to overlay measurements, then reprint. Avoid modifying the original file to preserve its accuracy for future use.
