A heating oil tank chart turns a stick reading into a gallon count, so you know how much fuel is left and when to schedule a delivery. This set of 46 charts covers common residential tank sizes and shapes, converting inches of depth into approximate gallons. Homeowners, property managers, and fuel delivery drivers can read the level and get a usable number without doing the math by hand.
The charts come as print-ready PDFs that print clearly for the basement wall or a clipboard by the tank. Laminate a copy so it stands up to a damp utility room. Tank shapes vary, so match the chart to your tank size for the closest estimate. Download the chart that fits your tank and keep an eye on the gauge through the winter.
